Descripciones

Large & Colorful LCD display

History records

90 degree rotatable pole clamp convenient for horizontal bar & vertical IV pole

Unique syringe intelligent recognition technology

Dynamically display the pressure

Double CPU ensuring safe infusion

RS232 interface

Adjustable buzzer volume

Anti-bolus function

Various Visual and audible alarms

Especificaciones

Infusion mode	Dose mode, Time mode, Rate mode
Applicable syringes	Various brands of sterile syringes: 5ml,10ml,20ml,30ml,50ml/60ml
Accuracy	±2% (after syringe correct calibration)
Infusion rate	5ml syringe: 0.1 -150ml/h 10ml syringe: 0.1 -300ml/h  20ml syringe: 0.1 -600ml/h    30ml syringe: 0.1 -900ml/h 50ml syringe: 0.1 -1500ml/h
Volume to be infused (VTBI)	0～1000 ml
Volume Infused (∑)	0～9999.9 ml
KVO rate	0.1-2 ml/h adjustable; default value: 0.1ml/h
Bolus rate	5ml syringe: 100-150ml/h 10ml syringe: 100-300ml/h 20ml syringe: 100-600ml/h  30ml syringe: 100-900ml/h 50ml syringe: 100 -1500ml/h
Alarms	Infusion completion, Empty, Occlusion, Near completion, Low battery, Syringe disengaged, No AC power supply, Battery exhausted, Malfunction etc.
Power supply	AC: 100~240V, 50/60Hz DC: 12V ±1.2V
Power consumption	25VA
Nurse call alarm	Optional
Classification	Class I, type CF
Dimensions	300(L)x 130(H)x 125 (W)mm, not including pole clamp
Net weight	1.8KG
Waterproof Level	IPX3
Occlusion pressure	(40.0-160.0)kpa
3 adjustable occlusion pressure settings	low, middle and high
Battery	Rechargeable Li polymer battery,7.4V, 1900mAh Can operate more than 12 hours after fully charged at 5ml/h., temperature 25℃
Battery recharge time	10h with power on, 3h with power off
Operating conditions	Temperature: 5℃~40℃, Relative humidity: 10~95%, Atmosphere pressure: 86～106kPa
Transport conditions	Temperature: -20℃~+60℃, Relative humidity: 10~95%, Atmosphere pressure: 50～106kPa
Storage conditions	Temperature: -20℃~+45℃, Relative humidity: 10~95%, Atmosphere pressure: 50～106kPa
